High Quality 50PCS SC APC fiber optic SC APC Single-mode Fast connector SC APC FTTH Fiber Optic quick Connector Free shipping
High Quality 50PCS SC APC fiber optic SC APC Single-mode Fast connector SC APC FTTH Fiber Optic quick Connector Free shipping - Image 2
High Quality 50PCS SC APC fiber optic SC APC Single-mode Fast connector SC APC FTTH Fiber Optic quick Connector Free shipping - Image 3
High Quality 50PCS SC APC fiber optic SC APC Single-mode Fast connector SC APC FTTH Fiber Optic quick Connector Free shipping - Image 4

High Quality 50PCS SC APC fiber optic SC APC Single-mode Fast connector SC APC FTTH Fiber Optic quick Connector Free shipping

$23.880

Please select a variation to see estimated shipping cost.
Get 10$ Off your Total Order Now! Make An Order Now Before This Offer Ends!
SKU: 33014655867 Categories: ,
Ominy Market
Ominy Market
Promotions
$10.000 OFF
$100.000 OFF
$80.000 OFF
$60.000 OFF
$40.000 OFF
$20.000 OFF
$5.000 OFF
Promotions
10$ OFF
Minimum spend 50$ Maximum spend $
Unlimited time
Apply Coupon
100$ OFF
Minimum spend 1376$ Maximum spend $
Unlimited time
Apply Coupon
80$ OFF
Minimum spend 744$ Maximum spend $
Unlimited time
Apply Coupon
60$ OFF
Minimum spend 620$ Maximum spend $
Unlimited time
Apply Coupon
40$ OFF
Minimum spend 372$ Maximum spend $
Unlimited time
Apply Coupon
20$ OFF
Minimum spend 74$ Maximum spend $
Unlimited time
Apply Coupon
5$ OFF
Minimum spend 15$ Maximum spend $
Unlimited time
Apply Coupon
Report Abuse

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

  • Model Number: SC/UPC
  • Connector Type: SC/APC
  • Fiber Type: Single Mode
  • Brand Name: BLHLI
  • Model Number: SC APC FTTH Fiber Optic Fast Connector
  • Quantity: 50 PCS
  • Splicing Type: SM, MM, DS, NZ-DS
  • Place of origin: China
  • Diameter: 0.9mm, 2.0mm, 3.0mm, Others
  • Loss: < 0.5dB
  • Durability: 500 Times
  • Application: FTTH FTTB FTTX Network
  • Mode: single mode, multimode
  • Storage Temperature: 25 ~ 85
  • Using temperature: -40~ 75°C

50PCS/box  SC APC fiber optic SC APC Single-mode Fast connector SC APC FTTH Fiber Optic quick Connector Free shipping



Specification





ITEM

Technical Parameters

Applicable for

Drop cable / Indoor cable

0.9mm Tight Buffer Fiber, 2.0mm, 3.0mm Drop Cable

Optical fiber diameter

SM(9/125), MM(50/125, 62.5/125)

125μm ( 657A & 657B )

Tight buffer diameter

250μm

Fiber mode

Single mode

Operation time

About 100s(no fiber cut)

Insert loss

≤ 0.3dB(1310nm & 1550nm)

Return loss

> 50db(PC), > 55db(UPC), > 65db(APC)

Fastening strength of naked fiber

>5 N

Fastening strength of naked fiber holder

>10 N

Tensile strength

>50 N

Using temperature

-40~+75°C

On-line tensile strength (20 N)

 IL ≤ 0.5dB  RL ≤ 5dB

Mechanical durability (500 times)

 IL ≤ 0.5dB  RL ≤ 5dB

Drop-off test (drop-off height 4m,once per direction, totally 3 times)

 IL ≤ 0.



Features:

1. FTTH project usable

2. Field installable

3. Insert loss less than 0.5dB

4. Metal V-shape cavity work well in high and low temperature

5. Installation less than 1 minutes

6. Reliable and superior optical performance
